ART MX524 Five Channel Four Zone Mic/Line Mixer

Art Pro Audio
Availability:

In stock
Add to wishlist
Compare
  • For Stage, Studio & Permanent Installs
  • 5 Input Channels
  • Combo XLR-1/4″ Inputs (Channels 1-4)
  • Stereo RCA on Channel 5
  • 4 Euroblock Zone Outputs
  • Level, Bass, Treble Controls
  • +48V Phantom Power on Inputs 1-4
  • LED VU Meters on All Outputs
  • 3.5mm TRS Headphone Jack
  • Separate Monitor Out + Telephone Paging

$749.99

In stock

Price Match

ART MX524 Five Channel Four Zone Mic/Line Mixer

SKU: ARTP_MX524CE Categories: , , ,
Weight 5.4521802874 kg
Dimensions 57.15 × 27.686 × 21.336 cm
brands

Art Pro Audio

Specification

Frequency Response 20 Hz to 20 kHz ±2 dB
Maximum Input Gain 60 dB Mic Input Main Out (XLR, Balanced)
50 dB Mic Input & REC. Out (Unbalanced)
60 dB Mic Input Mic. Out (Unbalanced)
60 dB Mic Input Mono Out (Unbalanced)
Impedance Microphone Input: 1.4 Kilohms
All Other Inputs 10 Kilohms or Greater
Zone Outputs 120 Kilohms
Monitor Speaker Output 8 Kilohms
Monitor Line Output 120 Kilohms
Phantom Power +48 VDC
Equalizer High: 10 kHz ±10 dB
Low: 100 Hz ±10 dB
Zone Output +26 dB (Balanced)
Monitor Out Monitor Line Output: +15 dB (Unbalanced)
Monitor Speaker Output: 1 W RMS / 8 Ohms
Headphone Output 0.5 W RMS / 47 Ohms
Connectors Inputs (Channels 1-4): Combo XLR-1/4″ / 6.35 mm (Balanced, Unbalanced)
Inputs (Channel 5): Stereo RCA (Unbalanced)
Outputs: Euroblock, Screw Terminals
Power 110 to 120 VAC, 50/60 Hz or 24 VDC
Dimensions (H x W x D) 5.1 x 19 x 7.5″ / 13 x 48.3 x 19.1 cm
Weight 6.6 lb / 3 kg

Packaging Info

Package Weight 12.02 lb
Box Dimensions (LxWxH) 22.5 x 10.9 x 8.4″
