Voyage Audio Spatial Mic Kit Ambisonic Microphone with USB/ADAT Connectivity

Designed for audio engineers, game sound-designers, AR/VR producers, and 3D audio pioneers, the Voyage Audio Spatial Mic is a professional second-order ambisonics VR microphone capable of single-wire connectivity to a computer or mobile device. It employs an array of eight 14mm condenser capsules to record in 360-degree, allowing the sound your viewers hear to change as they move and look around in a Virtual Reality or 360° video.

The Spatial Mic’s innovative design helps streamline the recording workflow associated with multi-channel microphone arrays. It employs built-in USB and ADAT Lightpipe connectivity, with no external mic preamps, multi-channel cables carrying analog signals, or converters needed. Live headphone monitoring is available. A calibration profile is stored within each mic to ensure consistent purity of signal. USB recording quality goes up to 24-bit/96 kHz.

The mic works in tandem with two powerful apps (free downloads available separately). Used in post-production, the Spatial Mic Converter DAW plug-in (VST, AAX, Mac OSX, and Windows 10) transforms the raw capsule output to first- or second-order ambisonic in AmbiX or Fuma formats, offering the capability to change the microphone’s aim to the point in space where the audio was initially recorded. The Spatial Mic Control app allows for remote operation of all hardware controls and more (Mac OSX and Windows 10).

Light, compact, and durable, the Spatial Mic features high-quality aluminum and nylon construction, making it ideal for recording both in the studio or in the field. The mic can either be bus-powered from a computer via USB Type-C, or for use with mobile devices, by an external power bank (available separately) via micro-USB.

To get you recording right out of the box, the Spatial Mic comes in a kit that includes USB Type-C and USB Type-A cables, a metal, 1/4″-20 to 5/8″-27 mini swivel ball for hard mounting to a microphone stand, and a foam windscreen.
