Mytek Brooklyn Bridge – Black
In stock
$3,299.00 $4,499.00
In stock
BROOKLYN BRIDGE
Brooklyn Bridge II is the result of a major redesign of our best selling original Brooklyn Bridge. The Brooklyn Bridge II now officially has a built in Roon Core combined with Mytek OS for easy touch screen operation from an ipad, smart phone or front panel screen.
BUILT IN ROON CORE I5 Intel CPU – POWERED BY ROON OS: Brooklyn Bridge has all functionality of a Roon Core CPU combined with high performance DAC. Roon Software can be operated from Roon Remote App or from Mytek Web Interface from any device connected to the network. Bridge can function as a multiroom playback machine playing to different Roon end points.
Thanks to ‘Darko audio’ Youtube channel for a great video.
Brooklyn Bridge 2 is all in-one Roon Core Streamer + excellent DSD/MQA DAC+ Analog (w/Phono) and Digital Preamp and a high-end headphone amplifier in a compact, modern beautiful chassis. It connects all your music sources in a highest sound quality hub before sending the music to amp and speakers or headphones. It’s powered by modern touch operated software – Roon for music browsing and streaming and Mytek OS for all other functionality. Software controls available on front panel are repeated on a wifi device: tablet or smartphone for comfort and convenience.
Music Sources:
Built in Roon Core: Tidal, Qobuz and local library in any format up to PCM 384kHz, DSD256 and MQA
Analog Preamp: Phono M/C and M/M and line RCA input
Digital Preamp: SPDIF and Optical inputs for disk players, or TV, Roon Ready DAC input for use w another streamer when required
Bluetooth 5: including hi-res audio (quality depends on cellphone) – For quick casual listening to any internet sound/music source.
Future Functions: Mytek OS is a software platform that is continuously expanded with new functionality added. Software upgrade happens the same way as on any computer: upon “new software” notification user can choose to download and update the system. New software contains new features and fixes. Within the next months and years, Mytek plans to add alternative players such as Spotify and Tidal Connect and features like Apple Airplay etc. Their availability will be announced when software work on them begins. Future Functions: Mytek OS is a software platform that is continuously expanded with new functionality added. Software upgrade happens the same way as on any computer: upon “new software” notification user can choose to download and update the system. New software contains new features and fixes. Within the next months and years, Mytek plans to add alternative players such as Spotify and Tidal Connect and features like Apple Airplay etc. Their availability will be announced when software work on them begins.
Inside the shipping box: power cord for country of destination, usb 2.0 cable, code for 2 months of FREE Roon subscription. Current manual is available as a pdf download on this page.
| Weight | 3.2 kg |
|---|---|
| Dimensions | 35 × 33 × 13 cm |
| brands | Mytek |
Specifications
| CONVERSION | up to 384k, 32bit PCM, native DSD up to DSD256, DXD, 130dB DR, ES9028PRO chipset with superior Mytek implementation (HAT ™ Harmonic Audio Tuning) |
| MQA HI-RES DECODER | DECODER: built-in hardware MQA decoder, full unfold to original sample rate |
| DIGITAL DAC INPUTS | USB2 Class2 (OSX, Linux driverless, all formats up to 384k, DSD256), 2x S/PDIF, 1 Toslink optical (PCM up to 24/192k, up to DSD64 DOP, MQA) |
| ADDITIONAL DIGITAL INPUTS | Bluetooth 5 and Roon Ready Network Endpoint DAC input – PCM384k, DSD256, MQA |
| ANALOG PREAMP INPUTS | Line level input (10k input impedance) or Phono M/M, M/C input, relay controlled. All analog signal path to output. |
| 2xUSB3/2 connectors | Can be used for: 1) Any music files on FAT / NTFS / Exfat drive or USB Stick. SSD is recommended because of 1A current limit) 2) additional USB DACs for additional Roon Zones (2pcs or up to several can be connected if USB hub is used) |
| ANALOG OUTPUTS | RCA, balanced XLR, simultaneous, 10 Ohm output impedance |
| CLOCK | Mytek Femtoclock Generator(tm) 0.82ps internal jitter |
| HEADPHONE OUTPUTS | Reference High Current, High transient Headphone Amp, 500mA, 6 Watts, dual headphone jacks, designed to drive hard-to-drive headphones. Balanced operation with a 1/4″ to 4 pin XLR adapter |
| VOLUME ATTENUATOR | Choice of 1dB step analog attenuator or 1dB step digital 32-bit attenuator and purist relay bypass |
| INTERNAL STORAGE | Internal storage is part of the system SSD on the main CPU board and it is fixed and not user upgradable. There are two models of BB2: basic 64GB (approx 10 CDs) and 4TB (approx 625 CDs). Internal storage is accessed by the user as a network drive. Upgrade to 4TB requires service by Mytek. |
| POWER SUPPLY | 90W Toroidal Linear Power Supply powers the DAC and the Intel I5 CPU from separate windings. Auto voltage detection adjusts to the local line voltage (90-240VAC 50/60Hz) |
| WEIGHT | 6lbs, 3kg |
| WARRANTY | 2 years |
| DIMENSIONS | WxDxH=8.5×8.8×1.74”=216x225x44mm |
