ESI U108 PRE 24-bit USB Audio Interface with 10 Microphone Preamps / 8 Outputs

Esi Audiotechnik
Availability:

In stock


  • High-Speed USB 2.0 Computer Interface
  • Up to 24-Bit / 96 kHz Resolution
  • 10 x Mic Preamps with Phantom Power
  • 2 x XLR-1/4″ Inputs with Hi-Z Switches
  • 8 x XLR 3-Pin Microphone Inputs
  • 8 x 1/4″ TRS Line Outputs
  • 2 x 1/4″ Mix Outputs, 1/4″ Headphone Out
  • Power, 48 VDC & Input Level LEDs
  • Includes Power Adapter & USB Cable
  • Compatible with Mac & Windows Computers

$819.99

In stock

The ESI U108 PRE is your gateway to professional-grade audio recording, perfect for various applications including studio band recordings, live stage performances, and home podcasting sessions. With a plethora of features, this high-speed USB 2.0 audio interface is designed to meet the demands of musicians, DJs, and podcast producers.

Key Features:

  1. Ten Mic Preamps: The U108 PRE boasts ten microphone preamps, including two via combo jacks for versatile input options. Select the Hi-Z switch for optimal signal transfer when connecting instruments like guitars and bass.
  2. High-Resolution Audio: Capture your audio in pristine 24-bit/96 kHz resolution, ensuring every detail is faithfully reproduced.
  3. Phantom Power: Selectable phantom power for individual channels (1-2, 3-6, 7-10) accommodates both condenser and dynamic microphones.
  4. Flexible Outputs: Utilize the eight 1/4″ TRS line outputs to route submixes or individual tracks to external mixers, summing consoles, or multichannel headphone amplifiers.
  5. Integrated Monitoring Mixer: Take control with the integrated monitoring mixer, complete with input and output level adjustments for precise monitoring. Choose between mono and stereo modes.
  6. LED Indicators: The front-panel LED indicators provide at-a-glance information on input levels, phantom power status, and power status.

Versatile Compatibility:

  • The U108 PRE seamlessly integrates with Mac and Windows computers, supporting CoreAudio on Mac and ASIO 2.0, MME, WDM, and DirectSound (including DirectWIRE) on Windows.

Additional Inclusions:

  • The package includes valuable software and licenses, such as Bitwig 8-Track DAW software for music production, Stanton’s Deckadance LE DJ software for mixing, and Audified’s inTone 2 ESI Edition for jamming.

With per-input gain control, robust connectivity options, and a wealth of bundled software, the ESI U108 PRE empowers you to elevate your audio projects to new heights. Whether you’re recording music, DJing, or podcasting, this versatile audio interface is your key to audio excellence.

Weight 2.8667037784 kg
Dimensions 58.42 × 17.78 × 10.16 cm
brands

Esi Audiotechnik

Specifications



Form Factor Desktop
Display None
Channels of I/O Analog:
10 Input / 8 Output at 96 kHz
Maximum Sampling Rate 96 kHz / 24-Bit
Number of Microphone Preamps 10 Preamps

Connectivity

Analog Audio I/O 2 x Combo XLR-1/4″ TRS Balanced/Unbalanced Mic/Line/Hi-Z Input
8 x XLR 3-Pin Balanced Mic Input
8 x 1/4″ TRS Balanced/Unbalanced Line Output
2 x 1/4″ TRS Balanced/Unbalanced Monitor Output
1 x 1/4″ TRS Unbalanced Headphone Output
Phantom Power 48 V (Selectable on Individual Inputs, on 4 Channels)
Digital Audio I/O None
Host Connection / USB 1 x USB Type-B
Host Connection Protocol USB 2.0
MIDI I/O None

Performance

Frequency Response AD/DA Converters:
20 Hz to 20 kHz ±0.02 dB
Dynamic Range A/D Converters:
107 dBA
D/A Converters:
112 dBA

Digital Audio

Sample Rates Up to 96 kHz (AD/DA Conversion)
Bit Depths Up to 24-Bit (AD/DA Conversion)
Sync Sources Internal
Audio Storage & Playback
Memory Card Slot None

Compatibility

OS Compatibility macOS 10.7 or Later
Windows 7
Windows 8.1
Windows 10
*As of June, 2022: Check with manufacturer for the most up-to-date compatibility
Required Hardware USB 2.0 Port
Internet Connection Required for Registration, Software/Driver Download

Power

Power Requirements AC/DC Power Adapter (Included)
AC/DC Power Adapter 12 VDC (Included)

Physical

Anti-Theft Features Kensington Security Slot
Dimensions 17.72 x 5.71 x 1.77″ / 45.01 x 14.5 x 4.5 cm
Weight 4.7 lb / 2.1 kg (without Accessories)

Packaging Info

Package Weight 6.32 lb
Box Dimensions (LxWxH) 23 x 7 x 4″
